Features
- 416cc, 8.5bhp, 4stroke Japanese (Kubota)diesel engine
- Decompression mechanism interlocked with starter circuit.
- Attractive twin head lights with halogen lamps.
- Styled instrument panel.
- Large & attractive side indicators.
- Triple vortex combustion system.
- Foot operated diaphragm clutch.
- Oil-air cooling.
- Glow plug provided in engine.
- Low chassis overhang.
Technical Specifications
| Engine |
|---|
| Type |
4 stroke, single cylinder, compression ignition |
| Capacity |
416.6 cc |
| Max Power |
8.5 bhp( 6.25 kW) @ 3600 rpm |
| Max Torque |
20 Nm @ 2400 rpm |
| Suspension |
|---|
| Front |
Hydraulic brakes with tandem mater cylinder & auto adjuster |
| Rear |
Hydraulic brakes with tandem mater cylinder & auto adjuster |
| Tyres |
|---|
| Front |
4.5x10,8PR |
| Rear |
4.5x10,8PR |
| Electrical |
|---|
| System Voltage |
12V DC |
| Head Lamp |
35/35 W |
| Fuel Tank |
|---|
| Material |
Plastic |
| Capacity |
8 lit |
| Dimensions |
|---|
| Overall height |
1880 mm |
| Overall length |
3090 mm |
| Overall Width |
1300mm |
| Wheelbase |
2025 mm |
| Min Ground Clearance |
170 mm |
| Weights |
|---|
| GVW |
876 |
|
|
|
|
